Wuxi Jiunai Polyurethane Products Co., Ltd
บ้าน ผลิตภัณฑ์สายพานโพลียูรีเทน

Smooth Green Pu Round Belt For Rough Transmission Machine , Easily Connected

ประเทศจีน Wuxi Jiunai Polyurethane Products Co., Ltd รับรอง
ประเทศจีน Wuxi Jiunai Polyurethane Products Co., Ltd รับรอง
Customer satisfaction products , good service !

—— Mr. Alcioni possamai

we are very impressed with the quality of the belts you produced.

—— Mr.Mike

your products are very popular in my markets.

—— Mr. jone

สนทนาออนไลน์ตอนนี้ฉัน

Smooth Green Pu Round Belt For Rough Transmission Machine , Easily Connected

Smooth Green Pu Round Belt For Rough Transmission Machine , Easily Connected
Smooth Green Pu Round Belt For Rough Transmission Machine , Easily Connected Smooth Green Pu Round Belt For Rough Transmission Machine , Easily Connected Smooth Green Pu Round Belt For Rough Transmission Machine , Easily Connected Smooth Green Pu Round Belt For Rough Transmission Machine , Easily Connected

ภาพใหญ่ :  Smooth Green Pu Round Belt For Rough Transmission Machine , Easily Connected

รายละเอียดสินค้า:
Place of Origin: china
ชื่อแบรนด์: jiuna
ได้รับการรับรอง: ROHS
Model Number: Diameter 2mm-20mm
การชำระเงิน:
Minimum Order Quantity: 10 rolls
Packaging Details: Inner packing is plastic film .outer packing is carton
Delivery Time: Within 5 working days After receipt of your deposit
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 100.000 meters per Month
รายละเอียดสินค้า
hardness: 85A color: green
stretching rate: 1.5-3% Surface: rough
material: PU length: 400m/roll 300m/roll 200m/roll 100m/roll 30m/roll
แสงสูง:

pu round belt

,

pu extruded belt

Smooth Green Pu Round Belt For Rough Transmission Machine , Easily Connected
Details:
(1)Thermoplastic polyurethane material, easy to be melted jointed
(2)Reinforced by Polyester Cord or Steel Cord
(3)Temperature range -35°C - 80°C
(4)Shore A hardness range 80A - 98A
(5)With excellent resistance to flex, abrasion resistance, easy jointed
and other characteristics. Widely used in textile, packaging, printing,
machinery, electronic, glass, chemicals, ceramics and other industries,
especially in the ceramic industry, widely used in the facilities line the glaze,
 polishing lines, and transmission line.
(6)Round Belt:
Round Belt Dia. is from 2mm to 30mm
Smooth Belt with good surface finish; Rough belt with even surface roughness.
 They are used widely.
PU Round belt with reinforcement



Items NO.Φ

Least radius of gyration

Stretching rate

Maximum tensile rate

Hardness

Length of rolled

DIA(mm)

 In

mm

  %

Kg

Lbs

Shore( A)

Length of rolled

2mm

0.79

20

1.5-3%

0.3

0.7

95

400

2.5mm

0.87

22

1.5-3%

0.4

0.9

95

400

3mm

0.98

25

1.5-3%

0.7

1.6

90

400

3.5mm

1.18

30

1.5-3%

0.95

2.1

90

400

4mm

1.38

35

1.5-3%

1.2

2.7

90

200

5mm

1.57

40

1.5-3%

2.0

4.3

90

100

6mm

1.97

50

1.5-3%

3.2

7.0

90

100

7mm

2.17

55

1.5-3%

4.1

9.0

90

100

8mm

2.56

65

1.5-3%

5.0

11.0

90

100

9mm

2.95

75

1.5-3%

6.8

15.0

90

50

10mm

2.95

75

1.5-3%

7.7

17.0

90

50

12mm

3.94

100

1.5-3%

12.2

27.0

90

30

15mm

4.72

120

1.5-3%

17.7

39.0

90

30

18mm

5.71

145

1.5-3%

25.4

56.0

90

30

20mm

6.30

160

1.5-3%

31.3

69.0

90

30


Service commitment:
“ Quality for keeping going ,Credit to win the world”



Smooth Green Pu Round Belt For Rough Transmission Machine , Easily Connected 0Smooth Green Pu Round Belt For Rough Transmission Machine , Easily Connected 1
