Hardness 85A-90APU Round Belt Polyurethane Round Belt Transmission Belt Textile Machines

Hardness 85A-90APU Round Belt Polyurethane Round Belt  Transmission Belt  Textile Machines
Hardness 85A-90APU Round Belt Polyurethane Round Belt  Transmission Belt  Textile Machines Hardness 85A-90APU Round Belt Polyurethane Round Belt  Transmission Belt  Textile Machines Hardness 85A-90APU Round Belt Polyurethane Round Belt  Transmission Belt  Textile Machines Hardness 85A-90APU Round Belt Polyurethane Round Belt  Transmission Belt  Textile Machines

ภาพใหญ่ :  Hardness 85A-90APU Round Belt Polyurethane Round Belt Transmission Belt Textile Machines

รายละเอียดสินค้า:
Place of Origin: wuxi city of china
ชื่อแบรนด์: jiuna
ได้รับการรับรอง: ROHS
Model Number: dia8 mm
การชำระเงิน:
Minimum Order Quantity: 10 rolls
Packaging Details: Inner packing is plastic film .outer packing is carton
Delivery Time: Within 7 working days After receipt of your deposit
Payment Terms: T/T, 50% payment in advance ,50% balance before shipment ; Western Union ; L/C
Supply Ability: 96.000 meters per Month
รายละเอียดสินค้า
hardness: 85A stretching rate: 1.5-3%
material: PU color: green
length: 30m/roll Type: PU round belt
pre-tensioning: 1.5%-3%
แสงสูง:

pu round belt

,

green round belt

 Green Polyurethane Round Belt PaIndustrial Transmission Conveyor

PU rough Round Belt(smooth/rough)

(1)Thermoplastic polyurethane material, easy to be melted jointed,100% pure polyurethane

(2)Reinforced by Polyester Cord or Steel Cord

(3)Temperature range -35℃ - 80℃

(4)Shore A hardness range 80A - 98A

(5)With excellent resistance to flex, abrasion resistance, easy jointed and other characteristics. Widely used in textile, packaging, printing, machinery, electronic, glass, chemicals, ceramics and other industries, especially in the ceramic industry, widely used in the facilities line the glaze, polishing lines, and transmission line.

(6) Dia. is from 2mm to 30mm. Smooth Belt with good surface finish; Rough belt with even surface roughness. They are used widely.



Features:
Outstanding abrasion resistance
High tensile and tear strength
Resistance to oils, fuels,and oxygen
Good weatherability and high impact resistance
Low compression set


Application:
Newspaper conveying,
Packing machines,
Ceramic and stoneware processing plants,
Floor and roof tiles conveying,
Wood Working machineries,
Textile machines,
Paper industry machines,
Food grading machines, other food processing machines.



Items NO.Φ

Least radius of gyration

Stretching rate

Maximum tensile rate

Hardness

Length of rolled

DIA(mm)

 In

mm

  %

Kg

Lbs

Shore( A)

Length of rolled

2mm

0.79

20

1.5-3%

0.3

0.7

95

400

2.5mm

0.87

22

1.5-3%

0.4

0.9

95

400

3mm

0.98

25

1.5-3%

0.7

1.6

90

400

3.5mm

1.18

30

1.5-3%

0.95

2.1

90

400

4mm

1.38

35

1.5-3%

1.2

2.7

90

200

5mm

1.57

40

1.5-3%

2.0

4.3

90

100

6mm

1.97

50

1.5-3%

3.2

7.0

90

100

7mm

2.17

55

1.5-3%

4.1

9.0

90

100

8mm

2.56

65

1.5-3%

5.0

11.0

90

100

9mm

2.95

75

1.5-3%

6.8

15.0

90

50

10mm

2.95

75

1.5-3%

7.7

17.0

90

50

12mm

3.94

100

1.5-3%

12.2

27.0

90

30

15mm

4.72

120

1.5-3%

17.7

39.0

90

30

18mm

5.71

145

1.5-3%

25.4

56.0

90

30

20mm

6.30

160

1.5-3%

31.3

69.0

90

30



Hardness 85A-90APU Round Belt Polyurethane Round Belt  Transmission Belt  Textile Machines 0Hardness 85A-90APU Round Belt Polyurethane Round Belt  Transmission Belt  Textile Machines 1
