Oil Resistance Polyurethane V Belt , 90A Polyurethane Timing Belts
| Place of Origin | China |
|---|---|
| ชื่อแบรนด์ | Jiuna |
| ได้รับการรับรอง | ROHS |
| Model Number | A, B, C, D, M, Z |
| Minimum Order Quantity | 600 Meter |
| Packaging Details | Inner packing is plastic film .outer packing is carton |
| Delivery Time | Within 7 working days After receipt of your deposit |
| Payment Terms | T/T, 50% payment in advance ,50% balance before shipment, T/T, Western Union |
| Supply Ability | 90.000 meters per Month |
ติดต่อฉันสำหรับตัวอย่างฟรีและคูปอง
Whatsapp:0086 18588475571
วีแชท: 0086 18588475571
Skype: sales10@aixton.com
หากคุณมีข้อกังวลใด ๆ เราให้ความช่วยเหลือออนไลน์ตลอด 24 ชั่วโมง
xรายละเอียดสินค้า
| ความแข็ง | 90 ฝั่ง A | ความยาว | 30 เมตร /ม้วน |
|---|---|---|---|
| วัสดุ | PU | สี | สีอะไรก็ได้ |
| อัตราการยืดกล้ามเนื้อ | 1.5%-3% | สเปค | ABCDMZ |
| เน้น | สายพานกลมสีเขียว สายพานปูรอบ 90 สายพาน A pu v,pu round belt,90 shore A pu v belt |
||
รายละเอียดสินค้า
Oil Resistance Polyurethane V Belt , 90A Polyurethane Timing Belts
PU V-Belt Application :
1. Widely used in textile
2. printing and packing machine
3. food & beverage processing
4. wood processing
5. paper processing
6. electronic
Product Technical Parameters :
|
Specification |
X(mm) |
H(mm) |
Z(mm) |
M/rolls |
reinforced |
arabesquitic |
|
A |
13 mm |
8 mm |
3.5mm |
30m |
·- |
·- |
|
B |
17 mm |
11 mm |
3.5mm |
30m |
·- |
·- |
|
C |
22 mm |
14 mm |
3.5mm |
30m |
·- |
·- |
|
D |
32 mm |
19 mm |
3.5mm |
30m |
·- |
·- |
|
M |
8 mm |
4 mm |
|
50m |
- |
- |
|
Z |
10 mm |
5 mm |
3.5mm |
50m |
·- |
·- |
Characteristics for PU V-section belt
1. excellent elasticity and damping characteristics
2. High tensile strength
3. With smooth surface v-belts
4. Color :red ,white
5. Hardness 90 shore A
6. Available with or without reinforced cord .
7. Replacement for conventional rubber V-belts , but more wear-resisting and can welding.
Products introduction
In addition , We are able to tailor Round and V-belts of different lengths and diameters - within a few days and with high quality.
Mainly used in transmission and distribution products for the textile, clothing, food, packaging, printing, machinery, electronic, g lass,chemicals,automobiles,beverages,furniture,toys,paper and other industries; especially in the ceramic industry, widely used in the glazing Lines, transmission lines, polishing line etc.
Normal specifications including Z,M,A,B,C,D and the Pentangular Belt including A,B,C type, pentagonal belt normally used in the production line’s corner
