Rough Polyurethane Round Belt Textile Machines 85A Low compression

Rough Polyurethane Round Belt Textile Machines 85A Low compression
Rough Polyurethane Round Belt Textile Machines 85A Low compression Rough Polyurethane Round Belt Textile Machines 85A Low compression Rough Polyurethane Round Belt Textile Machines 85A Low compression Rough Polyurethane Round Belt Textile Machines 85A Low compression

ภาพใหญ่ :  Rough Polyurethane Round Belt Textile Machines 85A Low compression

รายละเอียดสินค้า:
Place of Origin: wuxi city of china
ชื่อแบรนด์: jiuna
ได้รับการรับรอง: ROHS
Model Number: dia 12 mm
การชำระเงิน:
Minimum Order Quantity: 10 rolls
Packaging Details: Inner packing is plastic film .outer packing is carton
Delivery Time: Within 5 working days After receipt of your deposit
Payment Terms: T/T, 50% payment in advance ,50% balance before shipment ; Western Union
Supply Ability: 95.000 meters per Month
รายละเอียดสินค้า
hardness: 85A least radius gyration: 2.95 in
material: PU color: green
length: 30m/roll Type: PU roungh round belt
แสงสูง:

pu extruded belt

,

green round belt

Rough Polyurethane Round Belt Textile Machines 85A Low compression
Features:
Outstanding abrasion resistance
High tensile and tear strength
Resistance to oils, fuels,and oxygen
Good weatherability and high impact resistance
Low compression set

Application:
Newspaper conveying,
Packing machines,
Ceramic and stoneware processing plants,
Floor and roof tiles conveying,
Wood Working machineries,
Textile machines,
Paper industry machines,
Food grading machines, other food processing machines.


supply the connecting tools & Accessories for polyurethane belts , include clamp ,the Electric Iron and Knife , Connecting methods is hotpress welding , overlap welding .
The very elastic and flexible material PU 85 A ~90 A is particularly suitable for lead in conveyors and vertical shafts .



Items NO.Φ

Least radius of gyration

Stretching rate

Maximum tensile rate

Hardness

Length of rolled

DIA(mm)

 In

mm

  %

Kg

Lbs

Shore( A)

Length of rolled

2mm

0.79

20

1.5-3%

0.3

0.7

95

400

2.5mm

0.87

22

1.5-3%

0.4

0.9

95

400

3mm

0.98

25

1.5-3%

0.7

1.6

90

400

3.5mm

1.18

30

1.5-3%

0.95

2.1

90

400

4mm

1.38

35

1.5-3%

1.2

2.7

90

200

5mm

1.57

40

1.5-3%

2.0

4.3

90

100

6mm

1.97

50

1.5-3%

3.2

7.0

90

100

7mm

2.17

55

1.5-3%

4.1

9.0

90

100

8mm

2.56

65

1.5-3%

5.0

11.0

90

100

9mm

2.95

75

1.5-3%

6.8

15.0

90

50

10mm

2.95

75

1.5-3%

7.7

17.0

90

50

12mm

3.94

100

1.5-3%

12.2

27.0

90

30

15mm

4.72

120

1.5-3%

17.7

39.0

90

30

18mm

5.71

145

1.5-3%

25.4

56.0

90

30

20mm

6.30

160

1.5-3%

31.3

69.0

90

30



Rough Polyurethane Round Belt Textile Machines 85A Low compression 0
Rough Polyurethane Round Belt Textile Machines 85A Low compression 1Rough Polyurethane Round Belt Textile Machines 85A Low compression 2
